SPECIFICATIONS

4G Pocket WiFi Router Portable Mobile Hotspot 150Mbps 4G Wireless Router with SIM Card Slot Wide Coverage Broadband
Feature:
1. High-Speed 4G Connectivity: Enjoy fast and reliable internet access with speeds of up to 130 Mbps DL and 35 Mbps UL with this 4G pocket wifi router, ensuring smooth browsing, streaming, and downloading experiences.
2. Wide Frequency Band Support: This mobile hotspot supports various frequency bands including B1, B3, B5, and B40, providing flexibility and compatibility with different network carriers.
3. Enhanced WiFi Connectivity: With support for the 802.11b/g/n WiFi standard and MIMO technology, this wireless modem delivers a stable and efficient wireless connection, allowing multiple devices to connect simultaneously.
4. Versatile Compatibility: This 4G wireless router is compatible with web browsers, ensuring easy setup and configuration for users across different platforms and devices.
5. Portable and Long-Lasting: Featuring a 2100mAh lithium battery, this broadband offers on-the-go connectivity. Whether you're traveling or working remotely, you can stay connected for extended periods without worrying about running out of power.


Specification:
Model: H5577
Color: White
Support 4G frequency band: B1/B3/B5/B40
Frequency band:
DD-LTE: Cat4 130 Mbps DL/35Mbps
FDD-LTE: Cat4 150 Mbps DL /50Mbps
WiFi standard: 802.11b/g/n1"1
WCDMA: WCDMA: Downlink 21Mbp/UL 5.76Mbps
3GPP/3GPP2 protocol: LTE FDD/TDD version 9
Maximum number of WIFI users: 8-10
RF chip: RTR1605
Wireless MIMO technology
TDD-LTE: 21dbm 2dbm
Wireless transmission power:
FDD-LTE: 21dbm 2d
WCDMA: 2ldbm 2db
Support: 2.4GHz
Interface: USB
Compatibility: WEB Cross-browser compatibility
Battery: 2100mAh lithium battery
Working temperature: -10 C to 60 C
Working humidity: 5% -65%
Storage temperature: -30 C to 80 C
Storage humidity: 5% to 95%
Product size: 98 * 53 * 8mm/3.86 * 2.09 * 0.31in

How to use a router:
1. Push the rear cover down.
2. Insert the SIM card with the card core facing downwards
3. Insert the USB port into the power supply to obtain WiFi
4. Connect to WiFi and you can go online.
5. Connect to WIFI and open 192.168.100.1 in the browser to enter the background. The background can modify the WIFI name and password to add an APN.

Before purchasing, please read:
1. Before purchasing, you can check the frequency band in the link below to confirm if it meets local usage requirements

2. The frequency band used by the local country can be found in the following link

3. Frequency band query link used by local country operators
